Wireless Veterinarian Otoscope - Oto-ccd-Scope (ME16-VET)

Wireless video Otoscope - for the digital Veterinarian practice

oto ccd scope m-16
Informed Consent

Providing a path to informed consent is the key to better case acceptance amongst pet / animal owners.
The wireless Video Otoscope ME-16 increases owners understanding of their animals condition.
wireless video otoscope ME-16 The wireless feature provides super portability, as you can carry the camera around and diagnose patients anywhere. Nothing is more effective than a SHOW and TELL presentation right on the spot!

Improved Efficiency

The ME16-VET wireless video otoscope assists you and your patients owners to realize clarity and practicality in your daily practice.

Patients Visualization

Helping to visualize a medical condition provides a more thorough understanding, and creates a feeling of comfort for your patients owners. Even during the examination of a n animal, a parent can watch the animal's condition with the doctor. It leads to trust in a doctor's diagnosis and treatment plans.

Doga Clip Arm

Wireless

The truely wireless technology eliminates complicated installation or training. Super portability, high quality image, user friendly; it all fits in your hand.

The ME16-VET works with your existing display device such as TV / computer screen by using RFSYSTEMlab's wireless video receiver Morse (for TV / monitors) or USB-Morse (for computers). The displayed images can also be imported and saved into your imaging software (or patients' files).



m 16 comparison

m 16 comparison

Do your words of expalanation reach your patients owners during your examination?

Although they will not always admit it, most clients cannot fully understand your diagnostic by your explanation alone .
Using a traditional otoscope, you might be able to see what you need, but your clients will never really know what you see.
A picture is worth a thousand words.
Sharing images and videos with patients owners becomes the key to true informed consent.

otoscope m-16

Setup

Plug and Play system. Only 5 minutes to set it up by yourself without complicated wiring or office modification.
comparison otoscope

Setup

Nearly impossible to setup by yourself and office modification or complicated wiring is likely required.

Ease of use

All the necessary functions are within the compact body. Not only does the ergonomical design speed up your daily activities, but it also provides a safer, more comfortable and accurate diagnosis for your patients.

Ease of use

Too complicated to train your staff. The thick cable on the camera and the size of system is too cumbersome for a hectic daily practice.

Image Quality

White LED lights and our self-developed data processor ensure not only sharpness, but true-to-life color images.

Image Quality

Most companies still use a halogen light source which provides yellowish color images.

Portability

Weight: 6.4 oz
No strings attached and extremely portable just like your conventional otoscope. It can be carried from room to room.

Portability

Weight: 15 - 25 lbs
Because of the size and cables, it won't let you easily carry the system. Too heavy to carry and / or hard to push the cart around in tight spaces.

Price

Affordable price. Reasonable enough for any offices to have 2 or 3 systems.

Price

some other systems cost over $9,000. Regular Price : $7,800 - $9,000 (A camera and a docking station)

back to top

m16 specification m-16 otoscope details

CCD Sensor

m16 specification The high quality images can instantly be captured by the CCD sensor. The new SX630 data processor delivers smoother and lower noise images with realistic color.

16 Image On-Board Memory

The 16 image on-board memory can store images and review them on the spot. This can help achieve a fast and smooth informed consent process.

Fingertip Operation with Easy Focusing

RFSYSTEMLab wireless VET otoscope ME-16- specification The focus can be adjusted by turning the focus ring with one finger. Reaches up to 30 times magnification* and acheaves focus on wide range of areas such as ear drum, external acoustic meatus, fauces, etc..
*As seen on a 21-inch monitor.


RFSYSTEMLab wireless VET otoscope ME-16- specification
Specifications
sample images from RFSYSTEMLab wireless otoscope ME-16 * Weight:181.5g (6.4 oz)
* Length:220mm (8.7inch)
* Light Source:5 White LED
* Focus Depth:0 mm - Infinity (from Specula head)
* Wireless Video Signal: 2.4GHz Microwave Transmitter
* Video Transmission Range: 100 feet (direct line of sight)
* Data Processor: Full Digital SX630 Imaging Processor
* 16-Image Internal Memory Capacity (limitless when connected to a computer
* On-Board Memory: SDRAM 128MB
* Rechargable battery: 60 min. battery runtime
* Video Standard: NTSC/PAL
* Included attachment: Recharging Stand x1 / Specula x2 *

*Specula : different sizes can be exchanged for various uses. Diameters 4mm / 5mm / 7mm / 9mm are available /> * Welch Allyn specula can also be used.

bulletAvailable Accessories

*  Wireless Receivers For viewing the images on a TV, monitor or computer

*  Wireless Monitors For viewing the images on one of our wireless chairside monitors
